Product Model |
YN685 II (for Canon)
YN685 (for Nikon) |
Circuit design |
Insulated Gate Bipolar Transistor (IGBT) |
Guide No. |
60 (ISO 100, 200mm) |
Flash mode |
ETTL, M, Multi |
Trigger Mode |
Set-top, wireless off-camera |
Zoom range |
AUTO,20, 24, 28, 35, 50, 70, 80, 105, 135, 200mm |
Vertical rotation angle |
-7~90° |
Horizontal rotation angle |
0~360° |
Power supply |
4xAA size batteries (Alkaline or Ni-MH battery, NOT included in package) |
Light-emitting times |
100~1500 times (AA alkaline cell used) |
Recycle time |
Approx 3s (AA alkaline cell used) |
Color temperature |
5600k |
Flash time |
1/200s~1/20000s |
Flash control |
8 levels of output control (1/128~1/1), 22levels of fine tuning |
External interface |
External power inferface, PC port, hot shoe |
Wireless Triggering Distance |
Up to 100 m |
Triggering Distance |
20 ~ 25m Indoor, 10 ~ 15m Outdoor |
Dimensions |
67×77×210mm |
Net Weight |
426g |
